$97.99
- Easy, Fast Returns Guarantee
- The best quality products, always.
- Free Shipping Worldwide
- Quality You Can Trust
| Item | Compressor/Vacuum Pump |
|---|---|
| Compressor Type | Diaphragm |
| Free Air CFM @ 0 PSI | 1.40 |
| Full Load Amps | 9.5 |
| HP | 1/10 |
| Inlet Size | 1/8″ NPT |
| Max. PSI Cont./Int. | 35/35 |
| Max. Vacuum | 22.9 |
|---|---|
| Outlet Size | 1/8″ NPT |
| Overall Height | 4.75″ |
| Overall Length | 7.375″ |
| Overall Width | 4.25″ |
| Power Cord | No |
| Voltage | 12 VDC |
- 107 Series diaphragm vacuum pump suitable for liquid pumping operations in production, manufacturing, agriculture and industrial machinery applications
- Feature a permanently lubricated motor for quiet, smooth and maintenance-free operation
- Dual-base supports for easy mounting and providing added stability
- Free Air CFM @ 0 Vacuum (1.40)
- Free Air CFM @ 20 Vac (0.00)
- Free Air CFM @ 30 PSI (0.49)
| Height (cm) | 16 |
|---|---|
| Length (cm) | 27.94 |
| Width (cm) | 18.03 |
| HS Code | 8414801690 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 2.49 |
